Technical Data

(1) Operating temperature: -55℃ ~ +175 ℃, Max. shell temperature: +185 ℃.

(2) Input voltage: AC: 180V～340V

(3) Input AC frequency: 50Hz～400Hz

(4) Output voltage: up to two output channels, and two isolated output ground circuits: 12,15,18,24,36,48,72,100,150,200,250,300,400 (free combination)

(5) Output ripple: Less than 0.5% of output voltage

(6) Output power: 100W

(7) Temperature stability: Less than ±2.5% , typical ±1%

(8) Shock resistance: 25G, 0 ~ 300Hz

(9) Conversion efficiency: 80-90%

(10) Static power consumption: 1. 5W Max.

(11) Dimension: L: 180.0×W:38.0×H:16.9mm

(12) Isolation voltage between input and output: 1000V

(13) Output form of voltage: lead wire
